Model MY50L×4 CO2 Supercritical Extraction Machine
MODEL 200L( 50L X 4 )
This model is between 100L (50L×2) and 300L (50L×6). It has four extraction kettles, each with a capacity of 50L.
|
NO |
MAIN CONFIGURATION |
PARAMETERS |
|
1 |
Extraction Tank |
Volume:50L×4, Max working pressure: 40MPa |
|
2 |
Separation Tank |
Volume:20L×1+30L×1 , Max working pressure: 30MPa |
|
3 |
Pump |
CO2 high - pressure pump & carrier pump |
|
4 |
Cooling System |
Temperature range: 5°C - 10°C |
|
5 |
Heating Exchange System |
/ |
|
6 |
Purification System |
/ |
|
7 |
CO2 Storage Tank |
/ |
|
8 |
Safety Devices |
Pressure gauge at high - pressure pump outlet over pressure protection; extractor, separator, evaporator, dry purifier and mixer have safety valve to keep safe of system |
|
9 |
Temperature Control System |
Temperature range: Room temperature - 75°C |
|
10 |
Power Consumption |
89.5KW |
|
11 |
Installation size: |
7860mm × 4000mm ×5500mm |
|
12 |
User supplied |
CO2, 3 phase power |
